Storefront Glazing
Utilizing Cascadia’s award-winning Universal Series window frames, the Cascadia Storefront boasts significantly higher thermal and water resistance ratings compared to traditional, site-built storefront assemblies.

Description

Cascadia's novel storefront solution allows architects and specifiers to improve a notoriously weak point in a building’s assemblythe storefront assemblywhile at the same time offering developers and construction firms a simpler, lower cost option.

  • Factory-built, ready for quick on-site installation
  • Custom sizes & configurations
  • Commercial-grade fiberglass frames
  • Double (one Low-E), Triple (two Low-E) & Premium Triple (three Low-E)
  • LBC Red-List Free

Please direct inquiries to your Cascadia representative, or by email to:



Key Performance Data

US CAN
Air infiltration Rating (cfm/ft²) Rating (L/s/m²)
Universal Series Fixed Windows 0.00 0.00
400 Series Windows 0.00 0.01
Commercial Outswing Door - Single (41.5" x 96") 0.00 0.00
Water penetration psf pa
All Components 15 730
Design wind pressure psf pa
Universal Series Fixed Glazing (60" x 144") 100 4800
400 Series Fixed Glazing (60" x 144") 50 2400
Commercial Outswing Door - Single (41.5" x 96") 45 2160
  • Thermal Performance

    NFRC certified overall window U-values.
    • Standard Double Glazed, stainless edge spacer

      One low-E coating on surface #2 or 3

      Glass
      by
      Cardinal

      IGU Properties

      (NFRC method)

      U-values (Overall, NFRC method)
      Stainless Spacer
      90% Argon
      U-value, center of glass Solar Heat Gain  (SHGC) Visible Trans
      (VT)

      Fixed glazed

      Commercial Outswing Door: High-Performance Threshold

      Commercial Outswing Door: Low-Profile Threshold

      180 (#3) 0.26 0.68 79% 0.26 0.23 0.24
      272 (#2) 0.25 0.41 72% 0.25 0.23 0.24
      270 (#2) 0.25 0.37 70% 0.25 0.23 0.24
      366 (#2) 0.24 0.27 65% 0.24 0.22 0.23
      340 (#2) 0.25 0.18 39% 0.25 0.22 0.23



    • Glass
      by
      Cardinal

      IGU Properties

      (NFRC method)

      U-values (Overall, NFRC method)
      Stainless Spacer
      90% Argon
      U-value, center of glass Solar Heat Gain  (SHGC) Visible Trans
      (VT)

      Fixed glazed

      Commercial Outswing Door - High Performance Threshold Commercial Outswing Door - Low-Profile Threshold
      180/180 0.13 0.56 70% 0.15 0.15 0.16
      272/180 0.13 0.37 63% 0.14 0.15 0.15
      270/180 0.13 0.33 62% 0.14 0.15 0.15
      366/180 0.13 0.25 57% 0.14 0.15 0.15
      340/180 0.13 0.16 34% 0.14 0.15 0.15



    • Glass
      by
      Cardinal

      IGU Properties

      (NFRC method)

      U-values (Overall, NFRC method)
      Stainless Spacer
      90% Argon
      U-value, center of glass Solar Heat Gain  (SHGC) Visible Trans
      (VT)

      Fixed glazed

      Commercial Outswing Door: High-Performance Threshold
      180/180/i89 0.12 0.53 68% 0.13 0.14
      272/180/i89 0.11 0.36 62% 0.13 0.14
      270/180/i89 0.11 0.32 60% 0.13 0.14
      366/180/i89 0.11 0.24 56% 0.13 0.13
      340/180/i89 0.11 0.15 33% 0.13 0.14



    • Triple glazed, TriSeal Super Spacer

      Two low-E coatings on surfaces #2 and 5.

      Glass
      by
      Cardinal

      IGU Properties

      (NFRC method)

      U-values (Overall, NFRC method)

      TriSeal Super Spacer

      90% Argon

      U-value, center of glass Solar Heat Gain  (SHGC) Visible Trans
      (VT)
      Fixed glazed Commercial Outswing Door: High-Performance Threshold
      180/180 0.13 0.56 70% 0.15 0.15
      272/180 0.13 0.37 63% 0.14 0.14
      270/180 0.13 0.33 62% 0.14 0.14
      366/180 0.13 0.25 57% 0.14 0.14
      340/180 0.13 0.16 34% 0.14 0.14



    • Triple glazed, TriSeal Super Spacer

      Three low-E coatings on surfaces #2,4, and 6

      Glass
      by
      Cardinal

      IGU Properties

      (NFRC method)

      U-values (Overall, NFRC method)
      TriSeal Super Spacer
      90% Argon
      U-value, center of glass Solar Heat Gain  (SHGC) Visible Trans
      (VT)

      Fixed glazed

      Commercial Door Outswing: High-Performance Threshold
      180/180/i89 0.12 0.53 68% 0.13 0.14
      272/180/i89 0.11 0.36 62% 0.13 0.13
      270/180/i89 0.11 0.32 60% 0.13 0.13
      366/180/i89 0.11 0.24 56% 0.13 0.13
      340/180/i89 0.11 0.15 33% 0.13 0.13



    • STC/OITC Test Results

      Click here to see the acoustic performance of various window configurations.

      Window Type

      Glazing

      STC

      OITC

      Sample size

      Fixed Window

      Double 6/4

      34

      28

      47.25 x 59

      Fixed Window

      Triple 6Lami/4/6

      37

      27

      47.25 x 59

      Glass-only Data (calculated values), 1" IGU nominal Double 6/6 35 28 center-of-glass
      Glass-only Data (calculated values), 1.25" IGU nominal Double 6/6 38 31 center-of-glass
