The 400 Series is used for fixed, strip and large 'punched' window applications, with a deep frame section to permit large spans. It combines with our outswing operable window units (325 Series), to provide versatile glazing systems for residential, commercial and institutional projects.
Air Infiltration:
US - A3 (CFM/FT²)
CAN - A3 (L/S/M²)
Water Penetration:
US - 15.0 PSF
CAN - 730 PA
Design Wind Pressure:
400 Fixed (60" x 144") - CW-PG50-FW
50 PSF (2394 PA)
400 Fixed (144" x 60") - CW-PG70-FW
70 PSF (3351 PA)
400 Fixed (78" x 99") - CW-PG65-FW
65 PSF (3112 PA)
400 Fixed (99" x 78") - CW-PG65-FW
65 PSF (3112 PA)
400 Fixed (86" x 60") - CW-PG40-FW
40 PSF (1915 PA)
